출처: 금강종합상사





배관부속류>철나사이음쇠





Size(IN.)
A(mm)
4/1
23
3/8
23
1/2
27
3/4
32
1
38
11/4
46
11/2
48
2
57
21/2
69
Size(IN.)
A(mm)
4/1
23
3/8
23
1/2
27
3/4
33.3
1
36.5
11/4
43
11/2
47.5
2
55.5
21/2
69
Size(IN.)
A(mm)
4/1
37
3/8
37
1/2
40.5
3/4
48
1
53.5
11/4
59.5
11/2
65.5
2
73
21/2
82.5
3
90.5




Size(IN.)
A(mm)
3/8
19
1/2
21
3/4
25
1
29
11/4
34
11/2
37
2
42
Size(IN.)
B(mm)
4/1
9
3/8
12
1/2
14
3/4
17
1
19
11/4
23
11/2
26
2
32
Size(IN.)
H(최소)
(mm)
4/1
15
3/8
17
1/2
20
3/4
24
1
28
11/4
30
11/2
32
2
36



Size(IN.)
A(mm)
B(mm)
C(mm)
3/8 × 3/8 × 1/4
20
20
22
1/2 × 1/2 × 1/4
24
24
23
1/2 × 1/2 × 3/8
24
24
23
3/4 × 3/4 × 1/4
25
25
27
3/4 × 3/4 × 3/8
28
28
28
3/4 × 3/4 × 1/2
29
29
30
1 ×1 × 3/8
30
30
31
1 ×1 × 1/2
32
32
33
1 ×1 × 3/4
34
34
35
11/4 × 11/4 × 1/2
34
34
38
11/4 × 11/4 × 3/4
38
38
40
11/4 × 11/4 × 1
40
40
42
11/2 × 11/2 × 1/2
35
35
42
11/2 × 11/2 × 3/4
38
38
43
11/2 × 11/2 × 1
41
41
45
11/2 × 11/2 × 11/4
45
45
48
2 ×2 × 1/2
38
38
48
2 ×2 × 3/4
41
41
49
2 ×2 × 1
44
44
51
2 ×2 × 11/4
48
48
54
2 ×2 ×1 1/2
52
52
55
Size(IN.)
Width across flats B(mm)
L(mm)
E(mm)
Hex.
Oct.
1/2 × 1/4
26
-
21
16
1/2 × 3/8
26
-
21
16
3/4× 1/4
32
-
24
18
3/4 × 3/8
32
-
24
18
3/4 × 1/2
32
-
24
18
1 × 3/8
38
-
27
20
1 × 1/2
38
-
27
20
1 × 3/4
38
-
27
20
11/4 × 1/2
46
-
30
22
11/4 × 3/4
46
-
30
22
11/4 × 1
46
-
30
22
11/2 × 1/2
54
-
32
23
11/2 × 3/4
54
-
32
23
11/2 × 1
54
-
32
23
11/2 × 11/4
54
-
32
23
2 × 3/4
-
63
36
25
2 ×1
-
63
36
25
2 ×1 1/4
-
63
36
25
2 × 11/2
-
63
36
25
2 × 1
-
80
36
28
21/2 × 11/4
-
80
39
28
2 1/2 ×1 1/2
-
80
39
28
2 1/2 ×2
-
80
39
28
Size(IN.)
A(mm)
3/8 × 1/4
28
1/2 × 1/4
34
1/2× 3/8
34
3/4 × 1/4
38
3/4 × 3/8
38
3/4 × 1/2
38
1 × 3/8
42
1 × 1/2
42
1 × 3/4
42
11/4 × 1/2
48
11/4 × 3/4
48
11/4 × 1
48
11/2 × 1/2
52
11/2 × 3/4
52
11/2 × 1
52
11/2 × 11/4
52
2 × 1/2
58
2 ×3/4
58
2 × 1
58
2 × 11/4
58
2 ×1 1/2
58
