■ CHAIN BLOCK |
 |
|
Capacity
(ton) |
S.W.L |
Lift
Safe working Load |
Pulling Efforts |
|
lbs |
(kgs) |
feet |
(m) |
lbs |
(kgs) |
|
0.5 |
1,100 |
500 |
8.2 |
2.5 |
59.4 |
27 |
|
1 |
2,200 |
1,000 |
8.2 |
2.5 |
66.0 |
30 |
|
1.5 |
3,300 |
1,500 |
8.2 |
2.5 |
72.6 |
33 |
|
2 |
4,400 |
2,000 |
9.8 |
3.0 |
77.0 |
35 |
|
3(1F) |
6,600 |
3,000 |
9.8 |
3.0 |
94.6 |
43 |
|
3(2F) |
6,600 |
3,000 |
9.8 |
3.0 |
75.6 |
34 |
|
5 |
11,000 |
5,000 |
9.8 |
3.0 |
85.8 |
39 |
|
10 |
22,000 |
10,000 |
11.5 |
3.5 |
107.8 |
49 |
|
15 |
33,000 |
15,000 |
11.5 |
3.5 |
114.6 |
52 |
|
20 |
44,000 |
20,000 |
11.5 |
3.5 |
119x2 |
54x2 |
|
30 |
66,000 |
30,000 |
11.5 |
3.5 |
119x2 |
52x2 | |
|
|
■ LEVER BLOCK |
 |
|
Capacity
(ton) |
S.W.L
(kg) |
Lift
(M) |
Pulling
Efforts
(kg) |
No.of
Load
Chain |
Drawn-up
Dimension
(G) |
Net
weight
(kg) |
|
1.5 |
1,500 |
1.5 |
23 |
1 |
370 |
12 |
|
3 |
3,000 |
1.5 |
34 |
1 |
470 |
20 |
|
6 |
6,000 |
1.5 |
36 |
2 |
580 |
32 | | |
|
